Polymer Flexible Anode

This continuous cable-like anode is an integrated auxiliary anode composed of a copper wire and a conductive polymer sheath. The copper core serves as a low resistance bus bar to deliver the required current over considerable distance without incurring substantial longitudinal voltage drop. And the extruded polymer layer seals the copper wire from chemical attack.

Prepackaged in a porous, non-woven fabric “sock” that contains high conductivity calcined petroleum coke breeze, it enhances the abrasion and damage resistance. The anode is generally located in close proximity to the structure to be protected, and provides uniform cathodic protection current to the entire structure. It is ideal for use in all kind of soil, especially well suited the environment where the resistivity is high or various.

Category:

Tags:

, , , ,

FEATURES

  • Uniform distribution of cathodic protection current over long distances
  • Minimal interference to other metal structures
  • Solve the shielding problem of complex pipe network even if the pipeline coating is seriously damaged
  • Easy field installing and splicing
  • Long service life

APPLICATIONS

Our polymer flexible anode can be easily field cut to appropriate lengths and be installed by laying it in a hand- or machine-dug trench or cable plowing. It is generally located in close proximity to the structure to be protected, and provides uniform cathodic protection current to the entire structure. It is ideal for use in all kind of soil, especially well suited the environment where the resistivity is high or various and where there are risks for interference with secondary structures.

  • External surface of buried transmission pipelines
  • External bottom of aboveground tank

Item No. Polymer Extrusion Cable Conductor Sock Diameter Length Current Output Design Life
JA-POL-FLA100-S Φ0.51” (Φ13 mm) #6 AWG Φ1.5” (Φ38 mm) 500 ft. (152 m) 15.8 mA/ft. (52 mA/m) 25 yrs.
JA-POL-FLA100-M Φ0.51” (Φ13 mm) #6 AWG Φ1.5” (Φ38 mm) 1000 ft. (305 m) 15.8 mA/ft. (52 mA/m) 25 yrs.
JA-POL-FLA100-M Φ0.51” (Φ13 mm) #6 AWG Φ1.5” (Φ38 mm) 1500 ft. (457 m) 15.8 mA/ft. (52 mA/m) 25 yrs.

Remarks: Customized lengths and current output variations are available at request.

Main Technical Parameters

Polymer Extrusion

Φ0.51” (Φ13 mm)

Sock Diameter

Φ1.5"(Φ38mm)

Bend Radius

5.9” (150mm)

Reel Length

1000ft.(305m)

Current Output

15.8 mA/ft. (52 mA/m)

Operation Temperaturre

-18ºC min.

Design Life

25 years

Packaging Information

Our polymer flexible anode is normally packed on wooden reel to ensure easy transportation and handling in the field. Steel reel can be supplied as required. We have strict packing protocols to guarantee safe delivery of our products. Clear shipping marks and documentation make delivery acceptance straightforward and simple.

Item No. Anode Length ( per reel) Reel Dimensions (Dia. x D) Weight Reel Qty
N.W. G.W. 20ft. container 40ft. container
JA-POL-FLA100-S 500 ft. (152 m) Φ36″x30″ (Φ914 x 812 mm) 473 lbs (215 kg) 540 lbs (245 kg) 24 48
JA-POL-FLA100-M 1000 ft. (305 m) Φ42” x 40” (Φ1067 x 1016 mm) 947 lbs (430 kg) 1036 lbs (470 kg) / /
JA-POL-FLA100-L 1500 ft. (457 m) Φ46” x 41” (Φ1168 x 1041 mm) 1421 lbs (645 kg) 1543 lbs (700 kg) / /

Remarks: Custom packing is available upon request.

Shipping Documents:

  • Proforma invoice
  • Packing list
  • Testing reports (Chemical Composition, Electrochemical Properties Test, Certificate of Compliance)
  • Certificate of origin (upon request)
