MMO Probe Anode

This probe anode is an through-wall impressed current anode used to protect the internal surfaces of condenser waterbox, pressure vessel, process tank, heat exchanger, intake/discharge piping, etc. It is comprised of MMO coated titanium rod and machined stainless steel housing with advanced sealing system subject to water-tight assembly. And the inactive area of the probe anode can be provided in varying lengths to accommodate the design and installation.



, , , ,

Quality Substrate Material
The titanium substrate of the anode is selected according to ASTM B265 Grade 1 standard requirements. The high purity titanium has proven excellent chemical corrosion resistance, low electrical resistance, and high mechanical integrity against damage.

Noble Metal Oxide Coating
The Ir–Ta (IrO2/Ta2O5) mixed metal oxide catalyst, sintered to the surface of titanium substrate, demonstrates high chemical stability when exposed to high current density. We are able to produce anodes with differing coating thickness and noble metal oxide ratios. Strict quality procedures are followed throughout the coating process to ensure appropriate coating thickness and adhesion.

Long Working Life
The MMO coating film on the probe rod creates a protective stable layer ensuring a low consumption of the anode. These anodes can have a life expectancy of 100 years based on a 3 A/m2 current density.

Strict Quality Control
By conforming to ISO 9001:2015 standards, our probe anodes are manufactured, inspected, and tested in accordance with our stringent quality control procedures to ensure peak performance.

Customized Configurations
With the help of our experienced engineers, we can customize the anode size, service life and output current to meet your specific needs upon request.

Main Technical Parameters




Iridium Oxide (IrO2), Tantalum Oxide (Ta2O5)




Brackish Water, Fresh Water, Seawater



Design Life

100 years


We employ rigorous foundry internal testing standards to ensure the optimum lifespan and performance of our Anodes. Each anode is labelled with a unique serial number for quality tracking. Third party testing is conducted by customer’s special request at extra charge.

Technical Measurement Chemical Composition Electrochemical Performance Physical Properties
Testing Standard ASTM E120 NACE TM0108 / ASTM D3359 Foundry ITP
Testing Content Chemical Analysis Current Output / Anode Life Dimensions & Weight / Coating Thickness
Equipment Optical Emission Spectrometer OBLF QSN 750 JCM-6000 Plus Scanning Electron Microscope / DWW-K-100 Galvanostat / VCC101A Multimeter Calibrated Digital Measuring Devices
