Titanium Conductor Bar

Regarded as an ideal auxiliary anode material, titanium conductor bars are a bus bar to interconnect anode elements. It is designed to evenly distribute current to MMO titanium-based anode for many cathodic protection(CP) and Electro-Osmotic-Pulse(EOP) applications.

Considering the attenuation of all linear anodes, sometimes auxiliary conductors must be augmented. The titanium conductor bar is particularly useful for controlling attenuation over long spans. It is commonly used with MMO ribbon anodes or MMO mesh anodes for impressed current cathodic protection of aboveground storage tank bottoms and reinforced concrete structures.

The titanium conductor bar and the MMO ribbon/mesh anode are laid vertically to form a lattice grid pattern, and the intersections are connected by spot welding. The connection to the power source is achieved by a special anode joint.



, , , ,

Quality Substrate Material

The conductor bar is pure titanium and its chemical composition complies with ASTM B265 Grade I. It can have a life expectancy of 50 years or more.

Element Grade I Grade II
Iron (Fe) 0.20% max. 0.30% max.
Carbon (C) 0.08% max. 0.08% max.
Nitrogen (N) 0.03% max. 0.03% max.
Hydrogen (H) 0.015% max. 0.015% max.
Oxygen (O) 0.18% max. 0.25% max.
Titanium (Ti) Remainder Remainder

Dimensional Stability

Thanks to its stable chemical composition, this aerospace material is mechanically strong as well as ductile. It is easy to form and install in applications where available space is restricted.

Coefficient of Thermal Expansion 8.7 × 10‑5 / K-1 (4.8 × 10-6 / in / in / ºK)
Thermal Conductivity @ 20ºC 15.6 W/mºK (9.0 BTU/hr·ft2·°F)
Electrical Resistivity @ 20ºC 56 × 10-6 Ω·cm (22 × 10-6 Ω·in)
Modules of Elasticity (Min.) 105 GPa (14,900,000 PSI)
Tensile Strength (Min.) 245 MPa (35,000 PSI)
Yield Strength (Min.) 175 MPa (25,000 PSI)
Elongation (Min.) 24%

Excellent Corrosion Resistance

The titanium conductor bar is highly resistant to corrosion in various environments. It can be utilized in sandy soil, coke, seawater, brackish water and other complex environments with the presence of oxygen evolution, chlorine evolution or a mixture of the two.The titanium conductor bar is highly resistant to corrosion in various environments. It can be applied to sandy soil, coke, seawater, brackish water and other complex environment with oxygen evolution, chlorine evolution or a mixture of the two.

Item No. Electrical Resistance Current Density Design Life
JA–TCB-01 0.005 Ω/ft. (0.015 Ω/m) 0.278 A/ft² (3.0 A/m²) 50 yrs.
JA–TCB-02 0.26 Ω/ft. (0.081 Ω/m) 50 yrs.

Easy Installation

Conveniently being cut and welded in the field, to suit various geometries, eliminating the need for time consuming saw cuts and grouting. This efficient installation helps reduce the total installed cost.


Item No. Width Thickness Coil Length Weight
JA–TCB-01 1/4” (6.35 mm) 0.025” (0.635 mm) 500 ft. (152 m) 8.4 lbs (3.8 kg)
JA–TCB-02 1/2” (12.7 mm) 0.035” (0.9 mm) 500 ft. (152 m) 17.2 lbs (7.8 kg)

Remarks: Customized configurations are available at request.


Main Technical Parameters






12.7×0.9 mm (1/2″ × 0.035″)

Surface Area

0.027 m²/m


500 ft. (152 m)


8.2 kg (18.07 lbs)

Electrical Resistance

0.081 Ω/m (0.26 Ω/ft.)

Current Density

3 A/m² (0.278 A/ft²)




Storage Tank

Design Life

≥ 50 years

Packaging Information

We have strict packing protocols to guarantee safe delivery of our products. Clear shipping marks and documentation make delivery acceptance straightforward and simple.

Item No. Coil Length Coil Dimensions Net Weight Gross Weight
JA-TCB-01 500 ft. (152 m) 15.5″ × 15.5″ × 1″ (390 × 390 × 24mm) 2.75 lbs (1.25 kg) 3.6 lbs (1.65 kg)
JA-TCB-02 500 ft. (152 m) 19″ x 19″ x 1.0″ (480 x 480 x 24 mm) 17.2 lbs (7.8 kg) 18.07 lbs (8.2 kg)

Remarks: Custom packing is available upon request.

Shipping Documents:

  • Proforma invoice
  • Packing list
  • Testing reports (Chemical Composition, Electrochemical Properties Test, Certificate of Compliance)
  • Certificate of origin (upon request)
